This interface models how a radio signal attenuates during propagation. More...
#include <IAnalogModel.h>
Public Member Functions | |
| virtual const IReception * | computeReception (const IRadio *receiver, const ITransmission *transmission, const IArrival *arrival) const =0 |
| Returns the reception for the provided transmission at the receiver. More... | |
| virtual const INoise * | computeNoise (const IListening *listening, const IInterference *interference) const =0 |
| Returns the total noise summing up all the interfering receptions and noises. More... | |
| virtual const INoise * | computeNoise (const IReception *reception, const INoise *noise) const =0 |
| Returns the total noise summing up all the reception and the noise. More... | |
| virtual const ISnir * | computeSNIR (const IReception *reception, const INoise *noise) const =0 |
| Returns the signal to noise and interference ratio. More... | |
 Public Member Functions inherited from inet::IPrintableObject | |
| virtual | ~IPrintableObject () |
| virtual std::ostream & | printToStream (std::ostream &stream, int level, int evFlags=0) const |
| Prints this object to the provided output stream. More... | |
| virtual std::string | printToString () const |
| virtual std::string | printToString (int level, int evFlags=0) const |
| virtual std::string | getInfoStringRepresentation (int evFlags=0) const |
| virtual std::string | getDetailStringRepresentation (int evFlags=0) const |
| virtual std::string | getDebugStringRepresentation (int evFlags=0) const |
| virtual std::string | getTraceStringRepresentation (int evFlags=0) const |
| virtual std::string | getCompleteStringRepresentation (int evFlags=0) const |
Additional Inherited Members | |
| Public Types inherited from inet::IPrintableObject | |
| enum | PrintLevel { PRINT_LEVEL_TRACE, PRINT_LEVEL_DEBUG, PRINT_LEVEL_DETAIL, PRINT_LEVEL_INFO, PRINT_LEVEL_COMPLETE = INT_MIN } |
| enum | PrintFlag { PRINT_FLAG_FORMATTED = (1 << 0), PRINT_FLAG_MULTILINE = (1 << 1) } |
Detailed Description
This interface models how a radio signal attenuates during propagation.
It includes various effects such as free-space path loss, shadowing, refraction, reflection, absorption, diffraction and others.
Member Function Documentation
◆ computeNoise() [1/2]
|
pure virtual |
Returns the total noise summing up all the interfering receptions and noises.
This function never returns nullptr.
Implemented in inet::physicallayer::ScalarAnalogModelBase, inet::physicallayer::DimensionalAnalogModelBase, and inet::physicallayer::UnitDiskAnalogModel.
Referenced by inet::physicallayer::FlatReceiverBase::computeListeningDecision(), inet::physicallayer::ApskLayeredReceiver::computeListeningDecision(), inet::physicallayer::Ieee80211LayeredOfdmReceiver::computeListeningDecision(), and inet::physicallayer::RadioMedium::getNoise().
◆ computeNoise() [2/2]
|
pure virtual |
Returns the total noise summing up all the reception and the noise.
This function never returns nullptr.
Implemented in inet::physicallayer::ScalarAnalogModelBase, inet::physicallayer::DimensionalAnalogModelBase, and inet::physicallayer::UnitDiskAnalogModel.
◆ computeReception()
|
pure virtual |
Returns the reception for the provided transmission at the receiver.
The result incorporates all modeled attenuation. This function never returns nullptr.
Implemented in inet::physicallayer::LayeredDimensionalAnalogModel, inet::physicallayer::LayeredScalarAnalogModel, inet::physicallayer::UnitDiskAnalogModel, inet::physicallayer::DimensionalAnalogModel, and inet::physicallayer::ScalarAnalogModel.
Referenced by inet::physicallayer::RadioMedium::computeReception(), and inet::L3NetworkConfiguratorBase::computeWirelessLinkWeight().
◆ computeSNIR()
|
pure virtual |
Returns the signal to noise and interference ratio.
This function never returns nullptr.
Implemented in inet::physicallayer::ScalarAnalogModelBase, inet::physicallayer::DimensionalAnalogModelBase, and inet::physicallayer::UnitDiskAnalogModel.
Referenced by inet::L3NetworkConfiguratorBase::computeWirelessLinkWeight(), and inet::physicallayer::RadioMedium::getSNIR().
The documentation for this class was generated from the following file:
