#include <CcEnergySinkBase.h>

Inheritance diagram for inet::power::CcEnergySinkBase:

Public Member Functions
virtual A	getTotalCurrentGeneration () const override
	Returns the total current generation in the range [0, +infinity). More...

virtual void	addEnergyGenerator (const IEnergyGenerator *energyGenerator) override
	Adds a new energy generator to the energy sink. More...

virtual void	removeEnergyGenerator (const IEnergyGenerator *energyGenerator) override
	Removes a previously added energy generator from this energy sink. More...

Public Member Functions inherited from inet::power::EnergySinkBase
virtual int	getNumEnergyGenerators () const override
	Returns the number of energy generators in the range [0, +infinity). More...

virtual const IEnergyGenerator *	getEnergyGenerator (int index) const override
	Returns the energy generator for the provided index. More...

Public Member Functions inherited from inet::power::IEnergySink
virtual	~IEnergySink ()

Protected Member Functions
virtual A	computeTotalCurrentGeneration () const

virtual void	updateTotalCurrentGeneration ()

Protected Attributes
A	totalCurrentGeneration = A(NaN)

Protected Attributes inherited from inet::power::EnergySinkBase
std::vector< const IEnergyGenerator * >	energyGenerators

Additional Inherited Members
Static Public Attributes inherited from inet::power::ICcEnergySink
static simsignal_t	currentGenerationChangedSignal = cComponent::registerSignal("currentGenerationChanged")
	The signal that is used to publish current generation changes. More...

Member Function Documentation

◆ addEnergyGenerator()

void inet::power::CcEnergySinkBase::addEnergyGenerator ( const IEnergyGenerator * energyGenerator )

overridevirtual

Adds a new energy generator to the energy sink.

The energyGenerator parameter must not be nullptr.

Reimplemented from inet::power::EnergySinkBase.

Reimplemented in inet::power::CcEnergyStorageBase.

 {
     EnergySinkBase::addEnergyGenerator(energyGenerator);
     auto module = const_cast<cModule *>(check_and_cast<const cModule *>(energyGenerator));
     module->subscribe(ICcEnergyGenerator::currentGenerationChangedSignal, this);
     updateTotalCurrentGeneration();
 }

Referenced by inet::power::CcEnergyStorageBase::addEnergyGenerator().

◆ computeTotalCurrentGeneration()

A inet::power::CcEnergySinkBase::computeTotalCurrentGeneration ( ) const

protectedvirtual

 {
     A totalCurrentGeneration = A(0);
     for (auto energyGenerator : energyGenerators)
         totalCurrentGeneration += check_and_cast<const ICcEnergyGenerator *>(energyGenerator)->getCurrentGeneration();
     return totalCurrentGeneration;
 }

Referenced by inet::power::CcEnergyStorageBase::initialize(), and updateTotalCurrentGeneration().

◆ getTotalCurrentGeneration()

virtual A inet::power::CcEnergySinkBase::getTotalCurrentGeneration ( ) const

inlineoverridevirtual

Returns the total current generation in the range [0, +infinity).

Implements inet::power::ICcEnergySink.

Reimplemented in inet::power::SimpleCcBattery.

29 { return totalCurrentGeneration; }

◆ removeEnergyGenerator()

void inet::power::CcEnergySinkBase::removeEnergyGenerator ( const IEnergyGenerator * energyGenerator )

overridevirtual

Removes a previously added energy generator from this energy sink.

This functions throws an exception if the generator is not found.

Reimplemented from inet::power::EnergySinkBase.

Reimplemented in inet::power::CcEnergyStorageBase.

 {
     EnergySinkBase::removeEnergyGenerator(energyGenerator);
     auto module = const_cast<cModule *>(check_and_cast<const cModule *>(energyGenerator));
     module->unsubscribe(ICcEnergyGenerator::currentGenerationChangedSignal, this);
     updateTotalCurrentGeneration();
 }

Referenced by inet::power::CcEnergyStorageBase::removeEnergyGenerator().

◆ updateTotalCurrentGeneration()

void inet::power::CcEnergySinkBase::updateTotalCurrentGeneration ( )

protectedvirtual

Reimplemented in inet::power::SimpleCcBattery, and inet::power::CcEnergyStorageBase.

 {
     totalCurrentGeneration = computeTotalCurrentGeneration();
 }

Referenced by addEnergyGenerator(), removeEnergyGenerator(), and inet::power::CcEnergyStorageBase::updateTotalCurrentGeneration().

Member Data Documentation

◆ totalCurrentGeneration

A inet::power::CcEnergySinkBase::totalCurrentGeneration = A(NaN)

protected

Referenced by computeTotalCurrentGeneration(), inet::power::CcEnergyStorageBase::initialize(), inet::power::SimpleCcBattery::updateResidualCapacity(), inet::power::CcEnergyStorageBase::updateTotalCurrentGeneration(), and updateTotalCurrentGeneration().

The documentation for this class was generated from the following files:
