The layered error model computes the erroneous bits, symbols, or samples based on the SNIR and a simplified model of the signal processing. More...
#include <ILayeredErrorModel.h>
Public Member Functions | |
| virtual const IReceptionPacketModel * | computePacketModel (const LayeredTransmission *transmission, const ISnir *snir) const =0 |
| Computes the packet domain representation at the receiver using a simplified model for the underlying domains. More... | |
| virtual const IReceptionBitModel * | computeBitModel (const LayeredTransmission *transmission, const ISnir *snir) const =0 |
| Computes the bit domain representation at the receiver using a simplified model for the underlying domains. More... | |
| virtual const IReceptionSymbolModel * | computeSymbolModel (const LayeredTransmission *transmission, const ISnir *snir) const =0 |
| Computes the symbol domain representation at the receiver using a simplified model for the underlying domains. More... | |
| virtual const IReceptionSampleModel * | computeSampleModel (const LayeredTransmission *transmission, const ISnir *snir) const =0 |
| Computes the sample domain representation at the receiver using a simplified model for the underlying domains. More... | |
 Public Member Functions inherited from inet::IPrintableObject | |
| virtual | ~IPrintableObject () |
| virtual std::ostream & | printToStream (std::ostream &stream, int level, int evFlags=0) const |
| Prints this object to the provided output stream. More... | |
| virtual std::string | printToString () const |
| virtual std::string | printToString (int level, int evFlags=0) const |
| virtual std::string | getInfoStringRepresentation (int evFlags=0) const |
| virtual std::string | getDetailStringRepresentation (int evFlags=0) const |
| virtual std::string | getDebugStringRepresentation (int evFlags=0) const |
| virtual std::string | getTraceStringRepresentation (int evFlags=0) const |
| virtual std::string | getCompleteStringRepresentation (int evFlags=0) const |
Additional Inherited Members | |
| Public Types inherited from inet::IPrintableObject | |
| enum | PrintLevel { PRINT_LEVEL_TRACE, PRINT_LEVEL_DEBUG, PRINT_LEVEL_DETAIL, PRINT_LEVEL_INFO, PRINT_LEVEL_COMPLETE = INT_MIN } |
| enum | PrintFlag { PRINT_FLAG_FORMATTED = (1 << 0), PRINT_FLAG_MULTILINE = (1 << 1) } |
Detailed Description
The layered error model computes the erroneous bits, symbols, or samples based on the SNIR and a simplified model of the signal processing.
Member Function Documentation
◆ computeBitModel()
|
pure virtual |
Computes the bit domain representation at the receiver using a simplified model for the underlying domains.
This result includes all potential errors that were not corrected by the underlying domains.
Implemented in inet::physicallayer::Ieee80211OfdmErrorModel, inet::physicallayer::StochasticLayeredErrorModel, and inet::physicallayer::ApskLayeredErrorModel.
Referenced by inet::physicallayer::ApskLayeredReceiver::createBitModel(), and inet::physicallayer::Ieee80211LayeredOfdmReceiver::createBitModel().
◆ computePacketModel()
|
pure virtual |
Computes the packet domain representation at the receiver using a simplified model for the underlying domains.
This result includes all potential errors that were not corrected by the underlying domains.
Implemented in inet::physicallayer::Ieee80211OfdmErrorModel, inet::physicallayer::StochasticLayeredErrorModel, and inet::physicallayer::ApskLayeredErrorModel.
Referenced by inet::physicallayer::ApskLayeredReceiver::createPacketModel(), and inet::physicallayer::Ieee80211LayeredOfdmReceiver::createPacketModel().
◆ computeSampleModel()
|
pure virtual |
Computes the sample domain representation at the receiver using a simplified model for the underlying domains.
This result includes all potential errors that were not corrected by the underlying domains.
Implemented in inet::physicallayer::Ieee80211OfdmErrorModel, inet::physicallayer::StochasticLayeredErrorModel, and inet::physicallayer::ApskLayeredErrorModel.
Referenced by inet::physicallayer::ApskLayeredReceiver::createSampleModel(), and inet::physicallayer::Ieee80211LayeredOfdmReceiver::createSampleModel().
◆ computeSymbolModel()
|
pure virtual |
Computes the symbol domain representation at the receiver using a simplified model for the underlying domains.
This result includes all potential errors that were not corrected by the underlying domains.
Implemented in inet::physicallayer::Ieee80211OfdmErrorModel, inet::physicallayer::StochasticLayeredErrorModel, and inet::physicallayer::ApskLayeredErrorModel.
Referenced by inet::physicallayer::ApskLayeredReceiver::createSymbolModel(), and inet::physicallayer::Ieee80211LayeredOfdmReceiver::createSymbolModel().
The documentation for this class was generated from the following file:
