This interface models how a radio signal propagates through space over time. More...
#include <IPropagation.h>
Public Member Functions | |
| virtual mps | getPropagationSpeed () const =0 |
| Returns the theoretical propagation speed of radio signals in the range (0, +infinity). More... | |
| virtual const IArrival * | computeArrival (const ITransmission *transmission, IMobility *mobility) const =0 |
| Returns the time and space coordinates when the transmission arrives at the object that moves with the provided mobility. More... | |
 Public Member Functions inherited from inet::IPrintableObject | |
| virtual | ~IPrintableObject () |
| virtual std::ostream & | printToStream (std::ostream &stream, int level, int evFlags=0) const |
| Prints this object to the provided output stream. More... | |
| virtual std::string | printToString () const |
| virtual std::string | printToString (int level, int evFlags=0) const |
| virtual std::string | getInfoStringRepresentation (int evFlags=0) const |
| virtual std::string | getDetailStringRepresentation (int evFlags=0) const |
| virtual std::string | getDebugStringRepresentation (int evFlags=0) const |
| virtual std::string | getTraceStringRepresentation (int evFlags=0) const |
| virtual std::string | getCompleteStringRepresentation (int evFlags=0) const |
Additional Inherited Members | |
| Public Types inherited from inet::IPrintableObject | |
| enum | PrintLevel { PRINT_LEVEL_TRACE, PRINT_LEVEL_DEBUG, PRINT_LEVEL_DETAIL, PRINT_LEVEL_INFO, PRINT_LEVEL_COMPLETE = INT_MIN } |
| enum | PrintFlag { PRINT_FLAG_FORMATTED = (1 << 0), PRINT_FLAG_MULTILINE = (1 << 1) } |
Detailed Description
This interface models how a radio signal propagates through space over time.
Member Function Documentation
◆ computeArrival()
|
pure virtual |
Returns the time and space coordinates when the transmission arrives at the object that moves with the provided mobility.
The result might be an approximation only, because there's a tradeoff between precision and performance. This function never returns nullptr.
Implemented in inet::physicallayer::ConstantSpeedPropagation, and inet::physicallayer::ConstantTimePropagation.
Referenced by inet::physicallayer::RadioMedium::addRadio(), and inet::L3NetworkConfiguratorBase::computeWirelessLinkWeight().
◆ getPropagationSpeed()
|
pure virtual |
Returns the theoretical propagation speed of radio signals in the range (0, +infinity).
The value might be different from the approximation provided by the actual computation of arrival times.
Implemented in inet::physicallayer::PropagationBase.
Referenced by inet::physicallayer::MediumLimitCache::computeMaxRange(), and inet::physicallayer::FrequencyDependentAttenuationFunction::getValue().
The documentation for this class was generated from the following file:
