This interface represents the process of varying one or more physical properties of a periodic waveform, called the carrier signal, with a modulating signal that typically contains information to be transmitted. More...
#include <IModulation.h>
Public Member Functions | |
| virtual double | calculateBER (double snir, Hz bandwidth, bps bitrate) const =0 |
| Returns the bit error rate as a function of the signal to noise and interference ratio, the bandwidth, and the gross (physical) bitrate. More... | |
| virtual double | calculateSER (double snir, Hz bandwidth, bps bitrate) const =0 |
| Returns the symbol error rate as a function of the signal to noise and interference ratio, the bandwidth, and the gross (physical) bitrate. More... | |
 Public Member Functions inherited from inet::IPrintableObject | |
| virtual | ~IPrintableObject () |
| virtual std::ostream & | printToStream (std::ostream &stream, int level, int evFlags=0) const |
| Prints this object to the provided output stream. More... | |
| virtual std::string | printToString () const |
| virtual std::string | printToString (int level, int evFlags=0) const |
| virtual std::string | getInfoStringRepresentation (int evFlags=0) const |
| virtual std::string | getDetailStringRepresentation (int evFlags=0) const |
| virtual std::string | getDebugStringRepresentation (int evFlags=0) const |
| virtual std::string | getTraceStringRepresentation (int evFlags=0) const |
| virtual std::string | getCompleteStringRepresentation (int evFlags=0) const |
Additional Inherited Members | |
| Public Types inherited from inet::IPrintableObject | |
| enum | PrintLevel { PRINT_LEVEL_TRACE, PRINT_LEVEL_DEBUG, PRINT_LEVEL_DETAIL, PRINT_LEVEL_INFO, PRINT_LEVEL_COMPLETE = INT_MIN } |
| enum | PrintFlag { PRINT_FLAG_FORMATTED = (1 << 0), PRINT_FLAG_MULTILINE = (1 << 1) } |
Detailed Description
This interface represents the process of varying one or more physical properties of a periodic waveform, called the carrier signal, with a modulating signal that typically contains information to be transmitted.
Member Function Documentation
◆ calculateBER()
|
pure virtual |
Returns the bit error rate as a function of the signal to noise and interference ratio, the bandwidth, and the gross (physical) bitrate.
Implemented in inet::physicallayer::BpskModulation, inet::physicallayer::QbpskModulation, inet::physicallayer::MfskModulation, inet::physicallayer::MqamModulationBase, inet::physicallayer::MaskModulation, inet::physicallayer::MpskModulation, inet::physicallayer::DsssOqpsk16Modulation, inet::physicallayer::DpskModulationBase, inet::physicallayer::GfskModulationBase, inet::physicallayer::PpmModulationBase, and inet::physicallayer::Ieee80211OfdmModulation.
Referenced by inet::physicallayer::Ieee80211OfdmModulation::calculateBER(), inet::physicallayer::ApskErrorModel::computeBitErrorRate(), inet::physicallayer::ApskLayeredErrorModel::computeBitModel(), and inet::physicallayer::ApskLayeredErrorModel::computePacketModel().
◆ calculateSER()
|
pure virtual |
Returns the symbol error rate as a function of the signal to noise and interference ratio, the bandwidth, and the gross (physical) bitrate.
Implemented in inet::physicallayer::BpskModulation, inet::physicallayer::QbpskModulation, inet::physicallayer::MfskModulation, inet::physicallayer::MaskModulation, inet::physicallayer::MpskModulation, inet::physicallayer::MqamModulationBase, inet::physicallayer::DsssOqpsk16Modulation, inet::physicallayer::DpskModulationBase, inet::physicallayer::GfskModulationBase, inet::physicallayer::PpmModulationBase, and inet::physicallayer::Ieee80211OfdmModulation.
Referenced by inet::physicallayer::Ieee80211OfdmModulation::calculateSER(), inet::physicallayer::ApskErrorModel::computeSymbolErrorRate(), and inet::physicallayer::ApskLayeredErrorModel::computeSymbolModel().
The documentation for this class was generated from the following file:
